| Specifications | |
|---|---|
| Product type | Headphone amplifier and preamplifier |
| Amplification module | NFCA |
| Input | 1x Stereo RCA |
| Outputs | 1x Stereo RCA 1x Jack 6.35mm headphone outout |
| Headphone amplifier measurements | |
|---|---|
| THD+N @ 1kHz, A-Weighting | < 0.00006% @ 500mW, 32Ω < 0.00005% @ 80mW, 300Ω |
| THD @ 90kBw, 20Hz-20kHz | < 0.00008% @ 500mW, 32Ω < 0.00007% @ 80mW, 300Ω |
| SNR @ Max Out, 1kHz, A-Weighting | 144dB |
| Dynamic range @ 1kHz, A-Weighting | 144dB |
| Frequency response | 20Hz-40kHz (±0.05dB) |
| Output level | 14Vpp @ G=L 31Vpp @ G=M 37Vpp @ G=H |
| Noise level | < 0.3µVrms @ G=L < 0.3µVrms @ G=M < 1.4µVrms @ G=H |
| Crosstalk @ 1kHz | -92dB |
| Input sensitivity | 25Vrms @ G=L 11.2Vrms @ G=M 2.0Vrms @ G=H |
| Gain | -14dB @ G=L 0dB @ G=M 16.5dB @ G=H |
| Output impedance | < 0.1Ω |
| Output power | 2x3500mW @ 16Ω, THD+N < 0.1% 2x2700mW @ 32Ω, THD+N < 0.1% 2x2000mW @ 64Ω, THD+N < 0.1% 2x560mW @ 300Ω, THD+N < 0.1% |
| Load impedance | > 8Ω |
| Preamplifier measurements | |
|---|---|
| THD+N @ 1kHz, A-Weighting | < 0.00006% |
| THD @ 90kBw, 20Hz-20kHz | < 0.00007% |
| SNR @ Max Out, 1kHz, A-Weighting | 144dB |
| Dynamic range@ 1kHz, A-Weighting | 144dB |
| Frequency response | 20Hz-40kHz (±0.05dB) |
| Output level | 14Vpp @ G=L 31Vpp @ G=M 37Vpp @ G=H |
| Noise level | < 0.3µVrms @ G=L < 0.3µVrms @ G=M < 1.4µVrms @ G=H |
| Crosstalk @ 1kHz | -92dB |
| Input sensitivity | 25Vrms @ G=L Garanti Bilgisi
