Özellikler
• 2 x A Sınıfı Audient Konsolu Mic Preamp
• Sınıfının Lideri AD/DA Dönüştürücüler
• 1 x Ayrık JFET Enstrüman Girişi
• Ana ve Alt Hoparlör Çıkışları
• 1 x Bağımsız Çift Kulaklık Çıkışı
• 1 x ADAT Girişi ve Çıkışı
• 2 x Tam Dengeli Ekler
• Ultra Düşük Gecikmeli DSP Mikser
• Loop-back
• ScrollControl
• 3 x Kullanıcı Tanımlı Fonksiyon Tuşları
• Özel Kısma ve Kesme Kontrolleri
• +48V, Pad ve HPF Anahtarları
• USB 3.0 Uyumlu
• 24bit/96kHz
• Word Clock Çıkışı
• Tamamen Metal Tasarım
• Ücretsiz Yazılım + Eklentiler

Teknik Özellikler
Mikrofon Preamplifikatörü
• MIC GAIN: 0 to +58dB
• MAXIMUM INPUT LEVEL: +12dBu
• CROSSTALK: <-100dBu @ 1kHz & 10kHz
• THD+N: @0dBu 1kHz: 0.0015%, -96dB
• MIC EIN: -13dBu A-Weighted CMRR: >75dB@1kHz
• SNR: 97.5dB Unweighted, 100dB A-Weighted
• FREQUENCY RESPONSE: +/- 0.5dB 10Hz to 40kHz
• INPUT IMPEDANCE (Mic): 3kΩ balanced
• INPUT IMPEDANCE (Line): 10kΩ balanced
• PAD: -10dB
• HPF CUTOFF FREQUENCY: 100Hz
• PHANTOM POWER: 48V +/-4V @ 10mA/Channel
• XLR COMBI FEMALE: Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
• 1/4” TRS JACK: TIP (Hot), RING (Cold) & SLEEVE (Shield)

Line Girişler
• LINE GAIN:-10 to +48dB
• MAXIMUM INPUT LEVEL:+22dBU
• THD+N @0dBu 1kHz:0.0013%, -97dB

D.I / Enstrüman Girişi
• D.I GAIN:0 to 58dB
• MAXIMUM INPUT LEVEL:+12 dBu
• THD+N @ 0dBu (1kHz):0.0075%, -82dB
• SNR:95dB unweighted, 97.5dB A-weighted
• FREQUENCY RESPONSE:+/- 0.5dB 0.5dB 10Hz to 40kHz
• INPUT IMPEDANCE:500kΩ unbalanced
• 1/4” JACK:TIP (Hot) & SLEEVE (Shield)

ADC | Analog Digital Dönüştürücü
• MAXIMUM INPUT LEVEL:12.5dBu=0dBFS
• CROSSTALK:@1k -135dB, @10k -125dB
• FREQUENCY RESPONSE:+/- 0.2dB 0.5dB 10Hz to Fs/2 (Nyquist)
• THD+N @ -1dBFS (1kHz):0.0004%, -108dB
• DYNAMIC RANGE:122dB A-weighted
• INPUT IMPEDANCE:>10kΩ
• 1/4” JACK:TIP (Hot), RING (Cold) & SLEEVE (Shield)

DAC | Digital Analog Dönüştürücü
• MAXIMUM OUTPUT LEVEL:12dBu=0dBFS
• THD+N @ 1kHz -1dBFS:0.0003%, -110dB
• DYNAMIC RANGE:126.5dB A-weighted
• CROSSTALK:-130dB @ 1kHz, -115dB @ 10kHz
• FREQUENCY RESPONSE:+/- 0.1dB 10Hz to Fs/2 (Nyquist)
• OUTPUT IMPEDANCE:<100Ω
• 1/4” JACK:TIP (Hot), RING (Cold) & SLEEVE (Shield)

Kulaklık Çıkışı
• MAXIMUM OUTPUT LEVEL:18.5dBu=0dBFS
• THD+N @ -1dBFS (1kHz):0.0006%, -104dB
• DYNAMIC RANGE:124dB A-weighted
• CROSSTALK:-117dB @ 1kHz, -101dB @ 10kHz
• FREQUENCY RESPONSE:+/- 0.2dB 10Hz to Fs/2 (Nyquist)
• OUTPUT IMPEDANCE:<50Ω unbalanced
• MAX LEVEL INTO 30R:2.63V Peak, 1.87V RMS, 232mW
• MAX LEVEL INTO 60R:4.28V Peak, 3.03V RMS, 295mW
• MAX LEVEL INTO 600R:7.91V Peak, 5.6V RMS, 104mW

USB 2.0 Yüksek Hız
• NO. OF INPUT CHANNELS: 10 (2 Analogue, 8 Digital)
• NO. OF OUTPUT CHANNELS: 14 (6 Analogue, 8 Digital)
• Kablo Tipi: USB Type-C
• Beraberinde gelen kablo: 1m USB 2.0 Type-C to Type-C

Digital Giriş
• 8-CHANNEL ADAT:44.1kHz to 48kHz
• 4-CHANNEL ADAT:88.2kHz to 96kHz (SMUX)
• STEREO S/PDIF44.1kHz to 96kHz (Stereo)

Digital Çıkış
• 8-CHANNEL ADAT:44.1kHz to 48kHz
• 4-CHANNEL ADAT:88.2kHz to 96kHz (SMUX)
• STEREO S/PDIF44.1kHz to 96kHz (Stereo)

DSP Mikser
• Round Trip (in-to-out)
• 44.1kHz:0.344ms
• 48kHz:0.312ms to 96kHz (SMUX)
• 88.2kHz:0.188ms
• 96kHz:0.177ms

Word Clock Çıkışı
• 44.1kHz to 96kHz
